AWS Lambda Function Terraform Module

terraform-aws-arc-lambda-function

Latest Release Last Updated Terraform GitHub Actions

Quality gate

Overview

The ARC Terraform module provides a comprehensive and unified solution for deploying AWS Lambda functions on AWS. This versatile module supports multiple deployment methods including local source code, S3-based deployments, and container images, allowing you to choose the deployment approach that best fits your application requirements and operational needs.

Prerequisites

Before using this module, ensure you have the following:

  • AWS credentials configured.
  • Terraform installed.
  • A working knowledge of Terraform.

Getting Started

  1. Define the Module

Initially, it's essential to define a Terraform module, which is organized as a distinct directory encompassing Terraform configuration files. Within this module directory, input variables and output values must be defined in the variables.tf and outputs.tf files, respectively. The following illustrates an example directory structure:

1
2
3
4
lambda-function/
|-- main.tf
|-- variables.tf
|-- outputs.tf
  1. Define Input Variables

Inside the variables.tf or in *.tfvars file, you should define values for the variables that the module requires.

  1. Use the Module in Your Main Configuration In your main Terraform configuration file (e.g., main.tf), you can use the module. Specify the source of the module, and version, For Example
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
module "lambda-function" {
  source                 = "sourcefuse/arc-lambda-function/aws"
  version                = "0.0.1"

  # Basic configuration
  function_name = var.function_name
  description   = "Basic Lambda function example"
  runtime       = "python3.11"
  handler       = "lambda_function.lambda_handler"
  memory_size   = 128
  timeout       = 10

  # Deployment package
  filename         = data.archive_file.lambda_zip.output_path
  source_code_hash = data.archive_file.lambda_zip.output_base64sha256

  # Environment variables
  environment_variables = {
    ENVIRONMENT = var.environment
    LOG_LEVEL   = var.log_level
  }

  # CloudWatch Logs
  create_log_group      = true
  log_retention_in_days = 7

 tags = module.tags.tags
}
  1. Output Values

Inside the outputs.tf file of the module, you can define output values that can be referenced in the main configuration. For example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
output "arn" {
  description = "ARN of the Lambda function"
  value       = module.basic_lambda.lambda_function_arn
}

output "name" {
  description = "Name of the Lambda function"
  value       = module.basic_lambda.lambda_function_name
}

output "invoke_arn" {
  description = "Invoke ARN of the Lambda function"
  value       = module.basic_lambda.lambda_function_invoke_arn
}

output "role_arn" {
  description = "ARN of the Lambda execution role"
  value       = module.basic_lambda.lambda_role_arn
}

output "cloudwatch_log_group_name" {
  description = "Name of the CloudWatch log group"
  value       = module.basic_lambda.lambda_cloudwatch_log_group_name
}
  1. .tfvars

Inside the .tfvars file of the module, you can provide desired values that can be referenced in the main configuration.

First Time Usage

uncomment the backend block in main.tf

1
terraform init -backend-config=config.dev.hcl
If testing locally, terraform init should be fine

Create a dev workspace

1
terraform workspace new dev

Plan Terraform

1
terraform plan -var-file dev.tfvars

Apply Terraform

1
terraform apply -var-file dev.tfvars

Production Setup

1
terraform init -backend-config=config.prod.hcl

Create a prod workspace

1
terraform workspace new prod

Plan Terraform

1
terraform plan -var-file prod.tfvars

Apply Terraform

1
terraform apply -var-file prod.tfvars

Requirements

Name Version
terraform >= 1.3.0
archive >= 2.0
aws >= 5.0
null ~> 3.2

Providers

Name Version
aws 6.8.0
null 3.2.4

Modules

No modules.

Resources

Name Type
aws_cloudwatch_log_group.lambda resource
aws_iam_role.lambda resource
aws_iam_role_policy.lambda_execution resource
aws_lambda_alias.this resource
aws_lambda_function.this resource
aws_lambda_function_url.this resource
aws_lambda_permission.this resource
aws_lambda_provisioned_concurrency_config.this resource
aws_sqs_queue.dlq resource
null_resource.validate_deployment_package resource
null_resource.validate_package_compatibility resource
aws_caller_identity.current data source
aws_iam_policy_document.lambda_assume_role data source
aws_iam_policy_document.lambda_execution data source
aws_region.current data source

Inputs

Name Description Type Default Required
alias_description Description of the alias string "Lambda function alias" no
alias_function_version Lambda function version for which you are creating the alias string null no
alias_name Name for the alias string "live" no
alias_routing_config The Lambda alias routing configuration
object({
    additional_version_weights = map(number)
  })
 null no
architectures Instruction set architecture for your Lambda function list(string)
[
  "x86_64"
]
 no
attach_policy_statements Whether to attach additional policy statements to the Lambda role bool false no
code_signing_config_arn ARN of code signing config string null no
create_alias Whether to create an alias for the Lambda function bool false no
create_dlq Whether to create a dead letter queue (SQS) for the Lambda function bool false no
create_function_url Whether to create a Lambda function URL bool false no
create_log_group Whether to create a CloudWatch log group for the Lambda function bool true no
create_role Whether to create an IAM role for the Lambda function bool true no
dead_letter_config Dead letter queue configuration
object({
    target_arn = string
  })
 null no
description Description of what your Lambda Function does string "Lambda function created by Terraform" no
dlq_message_retention_seconds The number of seconds Amazon SQS retains a message in the DLQ number 1209600 no
dlq_name Name of the dead letter queue (if create_dlq is true) string null no
environment_variables Map of environment variables that are accessible from the function code during execution map(string) {} no
ephemeral_storage Ephemeral storage size in MB (512-10240) number 512 no
file_system_config File system configuration for the Lambda function
object({
    arn              = string
    local_mount_path = string
  })
 null no
filename Path to the function's deployment package within the local filesystem string null no
function_name Name of the Lambda function string n/a yes
function_tags A map of tags to assign specifically to the Lambda function map(string) {} no
function_url_config Lambda function URL configuration
object({
    authorization_type = string
    cors = optional(object({
      allow_credentials = optional(bool, false)
      allow_headers     = optional(list(string), [])
      allow_methods     = optional(list(string), [])
      allow_origins     = optional(list(string), [])
      expose_headers    = optional(list(string), [])
      max_age           = optional(number, 0)
    }))
    invoke_mode = optional(string, "BUFFERED")
  })

{
  "authorization_type": "AWS_IAM"
}
 no
handler Function entrypoint in your code string "index.handler" no
image_config Configuration for Lambda when using container images
object({
    command           = list(string)
    entry_point       = list(string)
    working_directory = string
  })
 null no
image_uri ECR image URI containing the function's deployment package string null no
kms_key_arn Amazon Resource Name (ARN) of the AWS Key Management Service (KMS) key that's used to encrypt your function's environment variables string null no
lambda_insights_enabled Whether to enable Lambda Insights for the function bool false no
lambda_insights_version Version of the Lambda Insights layer string "1" no
lambda_permissions Map of Lambda permissions to create
map(object({
    action                 = string
    principal              = string
    source_arn             = optional(string)
    source_account         = optional(string)
    statement_id           = optional(string)
    qualifier              = optional(string)
    function_url_auth_type = optional(string)
    principal_org_id       = optional(string)
  }))
 {} no
log_group_kms_key_id The ARN of the KMS Key to use when encrypting log data string null no
log_group_name Name of the CloudWatch log group string null no
log_retention_in_days Specifies the number of days you want to retain log events in the specified log group number 14 no
logging_config Logging configuration for Lambda function
object({
    log_format = string # e.g., "JSON" or "Text"
    log_group  = string # e.g., "/aws/lambda/my-function"
  })
 null no
memory_size Amount of memory in MB your Lambda Function can use at runtime number 128 no
package_type Lambda deployment package type (Zip or Image) string "Zip" no
policy_statements Map of policy statements to attach to the Lambda role
map(object({
    effect    = string
    actions   = list(string)
    resources = list(string)
    conditions = optional(map(object({
      test     = string
      variable = string
      values   = list(string)
    })), {})
  }))
 {} no
provisioned_concurrency_config Provisioned concurrency configuration
object({
    provisioned_concurrent_executions = number
    qualifier                         = string
  })
 null no
publish Whether to publish creation/change as new Lambda Function Version bool false no
replace_security_groups_on_destroy Whether to force replacement of security groups on destroy bool false no
replacement_security_group_ids List of replacement security group IDs to use list(string) [] no
reserved_concurrent_executions Amount of reserved concurrent executions for this lambda function number -1 no
role IAM role ARN attached to the Lambda Function. If not provided, a role will be created string null no
role_name Name of the IAM role to create (if create_role is true) string null no
role_path Path of the IAM role string "/" no
role_permissions_boundary The ARN of the policy that is used to set the permissions boundary for the role string null no
runtime Runtime for the Lambda function (e.g., python3.9, nodejs18.x, java11, etc.) string "python3.9" no
s3_bucket S3 bucket location containing the function's deployment package string null no
s3_key S3 key of an object containing the function's deployment package string null no
s3_object_version Object version containing the function's deployment package string null no
snap_start SnapStart configuration for Lambda function
object({
    apply_on = string # e.g., "PublishedVersions"
  })
 null no
source_code_hash Used to trigger updates. Must be set to a base64-encoded SHA256 hash of the package file specified with either filename or s3_key string null no
tags A map of tags to assign to the resource map(string) {} no
timeout Amount of time your Lambda Function has to run in seconds number 3 no
tracing_config Tracing configuration for Lambda function
object({
    mode = string # e.g., "Active" or "PassThrough"
  })
 null no
vpc_config VPC configuration for the Lambda function
object({
    subnet_ids         = list(string)
    security_group_ids = list(string)
  })
 null no

Outputs

Name Description
lambda_alias_arn The Amazon Resource Name (ARN) identifying the Lambda function alias
lambda_alias_description Description of the Lambda function alias
lambda_alias_function_version Lambda function version which the alias uses
lambda_alias_invoke_arn The ARN to be used for invoking Lambda Function alias from API Gateway
lambda_alias_name The name of the Lambda function alias
lambda_cloudwatch_log_group_arn The Amazon Resource Name (ARN) specifying the log group
lambda_cloudwatch_log_group_name The name of the CloudWatch Log Group
lambda_dead_letter_queue_arn The ARN of the SQS queue used as dead letter queue
lambda_dead_letter_queue_name The name of the SQS queue used as dead letter queue
lambda_dead_letter_queue_url The URL of the SQS queue used as dead letter queue
lambda_function_arn The Amazon Resource Name (ARN) identifying your Lambda Function
lambda_function_environment_variables The Lambda function environment variables
lambda_function_invoke_arn The ARN to be used for invoking Lambda Function from API Gateway
lambda_function_kms_key_arn The ARN of the KMS Key used to encrypt your Lambda Function's environment variables
lambda_function_last_modified The date this resource was last modified
lambda_function_name The name of the Lambda Function
lambda_function_qualified_arn The Amazon Resource Name (ARN) identifying your Lambda Function Version
lambda_function_signing_job_arn ARN of the signing job
lambda_function_signing_profile_version_arn ARN of the signing profile version
lambda_function_source_code_hash Base64-encoded representation of raw SHA-256 sum of the zip file
lambda_function_source_code_size The size in bytes of the function .zip file
lambda_function_tags The Lambda function tags
lambda_function_url The HTTP URL endpoint for the Lambda function
lambda_function_url_id The generated ID for the endpoint
lambda_function_version Latest published version of your Lambda Function
lambda_function_vpc_config The Lambda function VPC configuration
lambda_provisioned_concurrency_config_id The ID of the provisioned concurrency configuration
lambda_role_arn The Amazon Resource Name (ARN) specifying the Lambda IAM role
lambda_role_name The name of the Lambda IAM role
lambda_role_unique_id The stable and unique string identifying the Lambda IAM role

Versioning

This project uses a .version file at the root of the repo which the pipeline reads from and does a git tag.

When you intend to commit to main, you will need to increment this version. Once the project is merged, the pipeline will kick off and tag the latest git commit.

Development

Prerequisites

Configurations

  • Configure pre-commit hooks
    1
    pre-commit install

Versioning

while Contributing or doing git commit please specify the breaking change in your commit message whether its major,minor or patch

For Example

1
git commit -m "your commit message #major"
By specifying this , it will bump the version and if you don't specify this in your commit message then by default it will consider patch and will bump that accordingly

Tests

  • Tests are available in test directory
  • Configure the dependencies
    1
2
3
    cd test/
go mod init github.com/sourcefuse/terraform-aws-refarch-<module_name>
go get github.com/gruntwork-io/terratest/modules/terraform
  • Now execute the test
    1
    go test -timeout  30m

Authors

This project is authored by: - SourceFuse ARC Team
