AWS Redshift Terraform Module

terraform-aws-arc-redshift

Latest Release Last Updated Terraform GitHub Actions

Quality gate

Overview

The ARC Terraform-aws-arc-redshift module provides a comprehensive and unified solution for deploying Amazon Redshift data warehousing infrastructure on AWS. This versatile module supports both traditional Amazon Redshift provisioned clusters and the newer Redshift Serverless workgroups, allowing you to choose the deployment model that best fits your workload requirements and cost optimization needs.

Prerequisites

Before using this module, ensure you have the following:

  • AWS credentials configured.
  • Terraform installed.
  • A working knowledge of Terraform.

Getting Started

  1. Define the Module

Initially, it's essential to define a Terraform module, which is organized as a distinct directory encompassing Terraform configuration files. Within this module directory, input variables and output values must be defined in the variables.tf and outputs.tf files, respectively. The following illustrates an example directory structure:

1
2
3
4
redshift/
|-- main.tf
|-- variables.tf
|-- outputs.tf
  1. Define Input Variables

Inside the variables.tf or in *.tfvars file, you should define values for the variables that the module requires.

  1. Use the Module in Your Main Configuration In your main Terraform configuration file (e.g., main.tf), you can use the module. Specify the source of the module, and version, For Example
module "redshift" {
  source                 = "sourcefuse/arc-redshift/aws"
  version                = "0.0.1"

  namespace   = var.namespace
  environment = var.environment
  name        = var.name

  # Network configuration - using the subnets we created
  vpc_id     = data.aws_vpc.vpc.id
  subnet_ids = data.aws_subnets.private.ids

  # Cluster configuration
  database_name        = var.database_name
  master_username      = var.master_username
  manage_user_password = var.manage_user_password
  security_group_data    = var.security_group_data
  security_group_name           = var.security_group_name
  node_type            = var.node_type
  number_of_nodes      = var.node_count
  cluster_type         = var.node_count > 1 ? "multi-node" : "single-node"

  # Other configuration
  skip_final_snapshot = true
  publicly_accessible = false
  encrypted           = true

  tags = module.tags.tags
}
  1. Output Values

Inside the outputs.tf file of the module, you can define output values that can be referenced in the main configuration. For example:

output "redshift_cluster_id" {
  description = "The ID of the Redshift cluster"
  value       = module.redshift.redshift_cluster_id
}

output "redshift_cluster_endpoint" {
  description = "The connection endpoint for the Redshift cluster"
  value       = module.redshift.redshift_cluster_endpoint
}

output "redshift_endpoint" {
  description = "The endpoint of the Redshift deployment (either cluster or serverless)"
  value       = module.redshift.redshift_endpoint
}
  1. .tfvars

Inside the .tfvars file of the module, you can provide desired values that can be referenced in the main configuration.

First Time Usage

uncomment the backend block in main.tf

terraform init -backend-config=config.dev.hcl
If testing locally, terraform init should be fine

Create a dev workspace

terraform workspace new dev

Plan Terraform

terraform plan -var-file dev.tfvars

Apply Terraform

terraform apply -var-file dev.tfvars

Production Setup

terraform init -backend-config=config.prod.hcl

Create a prod workspace

terraform workspace new prod

Plan Terraform

terraform plan -var-file prod.tfvars

Apply Terraform

terraform apply -var-file prod.tfvars

Requirements

Name Version
terraform >= 1.5.0
terraform >= 1.5.0
aws ~> 5.0
random ~> 3.1

Providers

Name Version
aws 4.67.0

Modules

Name Source Version
redshift_cluster ./modules/redshift-cluster n/a
redshift_serverless ./modules/redshift-serverless n/a

Resources

Name Type
aws_caller_identity.current data source

Inputs

Name Description Type Default Required
additional_security_group_ids Additional security group IDs to be added to the Redshift Serverless workgroup. list(string) [] no
admin_password n/a string null no
admin_username Admin username for the Redshift Serverless namespace. string "admin" no
allow_version_upgrade If true, major version upgrades can be applied during maintenance windows bool true no
automated_snapshot_retention_period The number of days that automated snapshots are retained number 7 no
base_capacity The base data warehouse capacity in Redshift Processing Units (RPUs) number 32 no
cluster_identifier The Cluster Identifier string null no
cluster_parameter_group_name The name of the parameter group to be associated with this cluster string null no
cluster_subnet_group_name The name of a cluster subnet group to be associated with this cluster. If not specified, a new subnet group will be created string null no
cluster_type The cluster type to use. Either 'single-node' or 'multi-node' string "single-node" no
config_parameters A list of configuration parameters to apply to the Redshift Serverless namespace.
list(object({
parameter_key = string
parameter_value = string
}))
[] no
create_random_password Determines whether to create random password for cluster master_password bool true no
create_security_groups Whether to create security groups for Redshift Serverless resources bool true no
database_name The name of the database to create string n/a yes
egress_rules A list of egress rules for the security group.
list(object({
from_port = number
to_port = number
protocol = string
cidr_blocks = list(string)
}))
[] no
enable_serverless Enable Redshift Serverless. If true, creates the serverless module; if false, creates the standard cluster module. bool false no
encrypted If true, the data in the cluster is encrypted at rest bool true no
enhanced_vpc_routing If true, enhanced VPC routing is enabled bool false no
environment Name of the environment, i.e. dev, stage, prod string n/a yes
final_snapshot_identifier The identifier of the final snapshot that is to be created immediately before deleting the cluster string null no
ingress_rules A list of ingress rules for the security group.
list(object({
from_port = number
to_port = number
protocol = string
cidr_blocks = list(string)
}))
[] no
kms_key_id The ARN for the KMS encryption key string null no
manage_admin_password If true, Redshift will manage the admin password bool false no
manage_user_password Set to true to allow RDS to manage the master user password in Secrets Manager bool null no
master_password Password for the master DB user. If null, a random password will be generated string null no
master_username Username for the master DB user string n/a yes
max_capacity The maximum data warehouse capacity in Redshift Processing Units (RPUs) number 512 no
name Name for the Redshift resources string n/a yes
namespace Namespace of the project, i.e. arc string n/a yes
namespace_name The name of the Redshift Serverless namespace string null no
node_type The node type to be provisioned for the cluster string "dc2.large" no
number_of_nodes Number of nodes in the cluster number 1 no
port The port number on which the cluster accepts incoming connections number 5439 no
publicly_accessible If true, the cluster can be accessed from a public network bool false no
security_group_data (optional) Security Group data
object({
security_group_ids_to_attach = optional(list(string), [])
create = optional(bool, true)
description = optional(string, null)
ingress_rules = optional(list(object({
description = optional(string, null)
cidr_block = optional(string, null)
source_security_group_id = optional(string, null)
from_port = number
ip_protocol = string
to_port = string
self = optional(bool, false)
})), [])
egress_rules = optional(list(object({
description = optional(string, null)
cidr_block = optional(string, null)
destination_security_group_id = optional(string, null)
from_port = number
ip_protocol = string
to_port = string
prefix_list_id = optional(string, null)
})), [])
})
{
"create": false
}
no
security_group_name Redshift Serverless resourcesr security group name string "Redshift-Serverless-sg" no
skip_final_snapshot Determines whether a final snapshot of the cluster is created before Redshift deletes it bool false no
snapshot_identifier The name of the snapshot from which to create the new cluster string null no
subnet_ids List of subnet IDs for the Redshift subnet group list(string) [] no
tags Tags to apply to resources map(string) {} no
track_name Optional track name for Redshift Serverless (used for versioning or preview tracks). string null no
vpc_id ID of the VPC for Redshift string null no
vpc_security_group_ids A list of Virtual Private Cloud (VPC) security groups to be associated with the cluster list(string) [] no
workgroup_name The name of the Redshift Serverless workgroup string null no

Outputs

Name Description
redshift_cluster_arn The ARN of the Redshift cluster
redshift_cluster_database_name The name of the default database in the Redshift cluster
redshift_cluster_endpoint The connection endpoint for the Redshift cluster
redshift_cluster_hostname The hostname of the Redshift cluster
redshift_cluster_id The ID of the Redshift cluster
redshift_cluster_namespace_arn The ARN of the Redshift cluster
redshift_cluster_port The port of the Redshift cluster
redshift_cluster_security_group_id The ID of the security group associated with the Redshift cluster
redshift_database_name The name of the database in the Redshift deployment
redshift_endpoint The endpoint of the Redshift deployment (either cluster or serverless)
redshift_serverless_endpoint The endpoint URL for the Redshift Serverless workgroup
redshift_serverless_namespace_arn The ARN of the Redshift Serverless namespace
redshift_serverless_namespace_id The ID of the Redshift Serverless namespace
redshift_serverless_workgroup_arn The ARN of the Redshift Serverless workgroup
redshift_serverless_workgroup_id The ID of the Redshift Serverless workgroup
redshift_subnet_group_id The ID of the Redshift subnet group

Versioning

This project uses a .version file at the root of the repo which the pipeline reads from and does a git tag.

When you intend to commit to main, you will need to increment this version. Once the project is merged, the pipeline will kick off and tag the latest git commit.

Development

Prerequisites

Configurations

  • Configure pre-commit hooks
    pre-commit install


Versioning

while Contributing or doing git commit please specify the breaking change in your commit message whether its major,minor or patch

For Example

git commit -m "your commit message #major"
By specifying this , it will bump the version and if you don't specify this in your commit message then by default it will consider patch and will bump that accordingly

Tests

  • Tests are available in test directory
  • Configure the dependencies
    1
    2
    3
    cd test/
    go mod init github.com/sourcefuse/terraform-aws-refarch-<module_name>
    go get github.com/gruntwork-io/terratest/modules/terraform

  • Now execute the test
    go test -timeout  30m


Authors

This project is authored by: - SourceFuse ARC Team
